Description
General view of instruments and operating elements
48
BA RD24_RD28 en us 06
2.02 General view of instruments and operating elements
NOTE
All instruments and operating elements are marked by
numbers. You will find a description in chapter 3 under the
corresponding element.
000-04
NOTE
Please observe chapter 6, too. Here you find the description,
operator control and maintenance of auxiliary equipment.
000-64
2.02.01 Control stand
Operator’s platform
17246
501, 503 406
504
380 341 343 501, 503
302 310
[302] EMERGENCY STOP switch [310] Electrical system / engine start
switch
[341] Sprinkling switch [*343] Switch All-wheel lock
[*380] Switch Additive sprinkling [406] Socket 12 V
[501] Drive lever [503] Multifunction handle
[504] Engine speed
