Operation
Towing
92
BA RD24_RD28 en us 06
1. Drive lever [501] — CENTRE
2. Shut down diesel engine, if still functional.
3. Secure machine against rolling away with wedges or blocks.
4. Interrupt frictional connection of the hydrostatic drive (see text below).
5. Disable parking brakes (see text below).
6. Tow only with towing bar (brakes not functional).
Towing The machine may only be towed with low speed 1 km/h (0.6 mph). The
maximum towing distance is 500 m.
After towing 1. Shut down the diesel engine.
2. Secure machine against rolling away with wedges or blocks.
3. Reestablish frictional connection of the hydrostatic drive (see text
below)
4. Actuate parking brakes (see text below).
5. Remove towing bar.
Separating the hydrostatic
drive power train
Only if the oil flow can circulate without pressure in the hydraulic system,
can the machine be towed.
For this, perform the following at both high pressure valves:
1. Loosen lock nut [A] at the drive pump [C].
2. Screw in the locking screw [B] until the screw end flushes with the
lock nut.
Activating the hydrostatic
drive power train
1. Screw out the locking screw [B] until the stop.
2. Tighten lock nut [A].
