6-33
Phaser 3635MFP
dC109, dC131
General Procedures and Information
Draft 4
dC131 NVM Read/Write
Purpose
To review and modify values within the machine configuration and control parameters stored in
NVM.
Description
Each NVM item is identified using a chain and location code in the form XX-XXX, where XX- is
the chain prefix, and -XXX is an identifier in the range 001 to 999. For example 05-100.
Procedure
1. Enter diagnostics, GP 1.
2. Select Diagnostic Routines.
3. Select the required dC routine category:
• Copier Routines.
• Fax dC Routines.
4. Select 131 NVM Read/Write.
5. Select the appropriate button for the NVM chain to be viewed.
6. Use the scroll buttons to view the other NVM locations of the chain.
• Use the keyboard to type the three digit identifier code into the Find: field and then
touch the Find: button. This puts the found NVM value at the top of the list.
NOTE: Press the keypad C button to reset the Find: button to 000.
7. Touch the selected NVM in the list, and touch the Read/Write button.
• The Read/Write window will open for editable NVM, and the Read Only window will
open for Read Only (protected) NVM.
8. Refer to the tables that follow for NVM chain locations and parameters:
• Table 1 NVM chain 6
• Table 2 NVM chain 7
• Table 3 NVM chain 9
• Table 4 NVM chain 10
• Table 5 NVM chain 20
9. When the values of an editable NVM have been changed, switch off the machine, then
switch on the machine, to check and evaluate the changes made to the NVM.
SUB Subaddress
TCF Training check
TSI Transmitting subscriber identification
Table 1 Abbreviations
Term Description
