Xinje DF3E Series User Manual

125
5.4.6 Related parameters
The following parameters may be modified during auto-tuning. Do not change them manually during auto-tuning.
Parameter
Name
Property
The influence of numerical
value on gain after auto-tuning
P0-07
First inertia ratio
Gain
performance
parameters
Yes
P1-00
First speed loop gain
P1-01
Integral time constant of the first speed
loop
P1-02
First position loop gain
P2-00.0
Disturbance observer switch
P2-01.0
Adaptive mode switch
P2-35
Torque command filter time constant 1
P2-41
Disturbance observer gain
P2-47.0
model loop switch
P2-49
model loop gain
P2-55
model speed feedforward gain
P2-60.0
Active vibration suppression switch
P2-61
Active vibration suppression frequency
P2-62
Active vibration suppression gain
P2-63
Active vibration suppression damping
P2-64
Active vibration suppression filter time
1
P2-65
Active vibration suppression filter time
2
P2-66
Second group of active vibration
suppression damping
P2-67
Second group of active vibration
suppression frequency
P2-69.0
First notch switch
P2-69.1
Second notch switch
P2-71
First notch frequency
P2-72
First notch attenuation
P2-73
First notch band width
P2-74
Second notch frequency
P2-75
Second notch attenuation
P2-76
Second notch band width
P2-17
Inertia identification and internal
instruction auto-tuning max speed
Auto-tuning
setting
parameters
No
P2-86
auto-tuning jog mode
P2-87
auto-tuning min limit position
P2-88
auto-tuning max limit position
P2-89
auto-tuning max speed
P2-90
auto-tuning acceleration/deceleration
time
Note: P2-60~P2-67 are automatically modified in auto-tuning process. Users are not allowed to modify them
manually. Manual modification may lead to the risk of system runaway.
