8
2 Installation of servo system
2.1 Servo driver installation
2.1.1 Installation site
➢ Please install it in the installation cabinet without sunshine or rain.
➢ Do not use this product near corrosive and flammable gas environments such as hydrogen sulfide, chlorine,
ammonia, sulfur, chlorinated gas, acid, alkali, salt, etc.
➢ Do not install in high temperature, humidity, dust, metal dust environment;
➢ No vibration place.
2.1.2 Environment condition
2.1.3 Installation standard
Be sure to comply with the installation standard in the control cabinet shown in the figure below. This standard is
applicable to the situation where multiple servo drivers are installed side by side in the control cabinet (hereinafter
referred to as "when installed side by side").
To Next Page
