Alarm
code type
Alarm
code
Explanation
Property
Servo
status
when
alarming
Historical
records
Can be
cleared
Whether
power on is
needed to
clear the
alarm
1
E-061
Motor overheating
√
√
Yes
Servo
enable
3
E-063
Thermocouple
disconnection alarm
√
√
No
Servo
enable
08
0
E-080
Overspeed alarm
√
√
No
Servo off
09
2
E-092
Analog Tref
Zero-Calibration Over
limit
√
√
No
Servo
enable
3
E-093
Analog Vref
Zero-Calibration Over
limit
√
√
No
Servo
enable
10
0
E-100
Excessive position
deviation
√
√
No
Servo
enable
11
0
E-110
External UVW Short
Circuit Discovered in
Self-Inspection
√
√
No
Servo off
13
0
E-150
Power cable disconnection
√
√
No
Servo off
16
1
E-161
Driver thermal power
overload
√
√
No
Servo
enable
5
E-165
Anti-blocking alarm
√
√
No
Servo
enable
20
0
E-200
Regenerative resistance
overload
√
√
No
Servo
enable
22
0
E-220
Communication error of
absolute servo encoder
√
√
No
Servo off
1
E-221
Too many CRC errors in
encoder communication
√
√
No
Servo off
2
E-222
Absolute value servo
encoder battery low voltage
alarm
√
√
No
Servo off
3
E-223
Absolute value servo
encoder data access alarm
√
√
No
Servo off
7
E-227
Power on encoder multi-turn
signal data error
√
√
No
Servo off
8
E-228
Absolute Servo Encoder
Value Overflow
√
√
No
Servo off
24
0
E-240
Timing error in fetching
encoder position data
√
√
No
Servo off
1
E-241
Encoder reponse data is
error code
√
√
No
Servo off
26
0
E-260
Over range alarm
√
√
No
Servo
enable
1
E-261
Overrun signal connection
error
√
√
No
Servo
enable
2
E-262
Control stop timeout
√
√
No
Servo off
4
E-264
Excessive vibration
√
√
No
Servo
enable
5
E-265
Motor vibration too large
√
√
No
Servo
enable
28
0
E-280
Failed to access motor
parameters
√
○
Yes
Servo off
1
E-281
Error writing data to
encoder EEPROM
√
○
Yes
Servo off
