Circuit in the control valve
Back pressure (b) of the unload valve spring
chamber disappears and the oil pressure (a) from
the pump pushes up the unload valve.
The oil returns to the tank reducing the pressure.
The load check valve and the mechanical valve
remain closed.
(B) Load check valve
(C) Mechanical check valve
(D) Tank
(E) Unload valve
