3.7 SettingAlarmsonChannels
Set the alarms after setting the range. All alarm settings of a channel are cancelled in the
following cases.
• Whentheinputtype(Volt, TC, etc.) is changed.
• Whentheinputrangeischanged.
• Whentheupperorlowerlimitofthespanorscaleischangedonchannelsthatareset
to linear scale, square root computation, or 1-5 V (including changes in the decimal
point position).
SetupScreen
• AlarmsforEachChannel
Press MENU (to switch to setting mode), and select the Menu tab > Meas channel >
Range,Alarm.
• AlarmDelayTime
Press MENU (to switch to setting mode), and select the Menu tab > Meas channel >
Tag,Memorysample,Alarmdelay.
On DXs without the /AS1 advanced security option
