YOKOGAWA Daqstation DX2000 User Manual

10-4
IM 04L42B01-01E
• Ext.range>Unit
Set the unit. (Up to 6 characters,
A a # 1
;forreleasenumbers3andlater:°,Ω,andμ.)
• Alarm
The available alarm types are high limit alarm, low limit alarm, delay high limit alarm,
and delay low limit alarm.
The range of alarm values is as follows:
Type Value ExampleofaRangeofAlarmValues
H, L Within –30000 to 30000
excluding the decimal point.
Within –3000.0 to 3000.0 when the span
is 0.0 to 100.0.
T, t Same as H and L Same as H and L
For details on setting alarms, see section 3.7.
* If the external input channel On/Off or the decimal place of the span setting is changed, the
alarms for that channel are turned Off.
• Tag>Comment
Sets the tag comment. On a DX with a release number of 3 or later, you can enter up
to 32 characters.
On a DX with a release number of 2 or earlier, you can enter up to 16 characters. The
characters that can be entered are:
A a # 1
.
• Tag>No.(Releasenumber3orlater)
This setting only appears when you have enabled the use of tag numbers.
Sets the tag number. (Up to 16 characters:
A a # 1
)
• Memorysample>On/Off
Turn On the target channels.
• Alarmdelay>Time
For details on setting the alarm delay time, see section 3.7.
10.1SettingExternalInputChannels
