YOKOGAWA Daqstation DX2000 User Manual

13-7
IM 04L42B01-01E
Specifications
1
2
3
4
5
6
7
8
9
10
11
12
13
App
Index
ManualSampledData
Item Specifications
Item Measured value at an arbitrary time
Specify up to 120 channels when external input channels (/MC1) are used.
Maximum number of data values that
the internal memory can store
400
Data format Text
ReportData(/M1and/PM1)
Item Specifications
Item Report at each scheduled time of report
Maximum number of reports that the
internal memory can store
100
Data format Text or XML spreadsheet (release numbers 4 and later)
SnapshotData
Item Specifications
Item Displayed screen image data
Data format PNG
Output destination CF card, USB flash memory, or communication output
SavingDatatotheExternalStorageMedium
Item Specifications
Data Saving Saves the data in the internal memory to the external storage medium.
Manual save Saves when the external storage medium is inserted with a key operation.
Auto save
Display data:
Every file save interval
Event data:
Every data length
Manual sampled data:
When manual sampling is executed.
Report data:
When report is created.
Snapshot data:
When a snapshot is taken
Auto save operation Select “save data only if there is sufficient free space on the CF card” or “constantly
retain the most recent data files in the CF card (media FIFO)” (release number 2 or later).
File name Select from “sequence number+user-assigned string+date,” “sequence number+user-
assigned string,” or “sequence number+batch name.”
Save destination Auto save: CF card. Manual save: CF card or USB flash memory (/USB1)
Directory name: Specify using up to 20 characters.
ChangeSettingsLogData(/AS1;releasenumbers4andlater)
Item Specifications
Item Log of setting changes
Maximum number of data values that
the internal memory can store
200
Data format Text
Output destination (auto save) SET0 directory on the CF card
A file name that includes the execution date is automatically attached.
SetupData
Item Specifications
Item DX setup data
Data format Binary
File name Specify using up to 32 characters.
Output/read destination (for saving/loading)
CF card or USB flash memory (/USB1)
Output destination (auto save; when the settings are changed on a DX with the /AS1 option)
SET0 directory on the CF card
A file name that includes the execution date is automatically attached.
13.3DataSavingFunction
