Zebra DS6878 Product Reference Guide

5 - 30 DS6878 Product Reference Guide
FIPS Mode
Parameter # 736
The Federal Information Processing Standard (FIPS) 140-2 is a U.S. government computer security standard
used to accredit cryptographic modules. FIPS enabled DS6878 scanners and cradles offer this secure mode of
operation.
To enable the FIPS mode of operation (enabled by default), scan the Enable FIPS bar code. The scanner will
attempt to establish a secure session with the cradle to which it is connected. On success, the scanner will light
a yellow LED on every trigger pull to signal that all data will be transmitted over Bluetooth in a secure fashion.
On failure, the scanner will sound transmission failure error message on every attempt to transmit data.
To disable the FIPS mode, scan the Disable FIPS bar code at any time.
NOTE The CR0078-P cradle is required for FIPS mode.
*Enable FIPS
(1)
Disable FIPS
(0)

Zebra DS6878 Specifications

General

Wavelength	655 nm
Scanner type	2D
Yaw reading angle	-60 - 60 °
Decoding standards	1D, 2D, PDF417, PDF417, microPDF417, Composite Codes (CC-A, CC-B, CC-C), U.S. Postnet and Planet, U.K., Japan, Australian, Netherlands KIX code, Royal Mail 4 State Customer, UPU ICS 4 State Postal, USPS 4CB, TL C-39, Aztec (Standard, Inverse), MaxiCode, DataMatrix/ECC 200 (Standard, Inverse), QR Code (Standard, Inverse and Micro)
Tilt reading angle	-360 - 360 °
Input voltage	5 V
Bluetooth	Yes
Dimensions (WxDxH)	69 x 97 x 185 mm
Certification	FCC, RoHS
Product color	Black
International Protection (IP) code	IP43
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Cables included	USB

Weight and Dimensions

Weight	238 g
