Zebra DS6878 Product Reference Guide

Keyboard Wedge Interface 9 - 3
Keyboard Wedge Parameter Defaults
Table 9-1 lists the defaults for Keyboard Wedge host parameters. To change any option, scan the appropriate
bar code(s) in the Keyboard Wedge Host Parameters section beginning on page 9-4.
NOTE See Appendix A, Standard Default Parameters for all user preferences, hosts, symbologies, and
miscellaneous default parameters.
Table 9-1 Keyboard Wedge Host Default Parameters
Parameter Default
Page
Number
Keyboard Wedge Host Parameters
Keyboard Wedge Host Type IBM PC/AT& IBM PC Compatibles 9-4
Country Types (Country Codes) North American 9-5
Ignore Unknown Characters Send 9-7
Keystroke Delay No Delay 9-7
Intra-Keystroke Delay Disable 9-8
Alternate Numeric Keypad Emulation Disable 9-8
Caps Lock On Disable 9-9
Caps Lock Override Disable 9-9
Convert Wedge Data No Convert 9-10
Function Key Mapping Disable 9-10
FN1 Substitution Disable 9-11
Send and Make Break Send 9-11

Zebra DS6878 Specifications

General

Wavelength	655 nm
Scanner type	2D
Yaw reading angle	-60 - 60 °
Decoding standards	1D, 2D, PDF417, PDF417, microPDF417, Composite Codes (CC-A, CC-B, CC-C), U.S. Postnet and Planet, U.K., Japan, Australian, Netherlands KIX code, Royal Mail 4 State Customer, UPU ICS 4 State Postal, USPS 4CB, TL C-39, Aztec (Standard, Inverse), MaxiCode, DataMatrix/ECC 200 (Standard, Inverse), QR Code (Standard, Inverse and Micro)
Tilt reading angle	-360 - 360 °
Input voltage	5 V
Bluetooth	Yes
Dimensions (WxDxH)	69 x 97 x 185 mm
Certification	FCC, RoHS
Product color	Black
International Protection (IP) code	IP43
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Cables included	USB

Weight and Dimensions

Weight	238 g
