6 - 2 DS6878 Product Reference Guide
Scanning Sequence Examples
In most cases scanning one bar code sets the parameter value. For example, to disable image capture
illumination, scan the Disable Image Capture Illumination bar code under Image Capture Illumination on
page 6-5. The digital scanner issues a fast warble beep and the LED turns green, signifying a successful
parameter entry.
Other parameters require scanning several bar codes. See these parameter descriptions for this procedure.
Errors While Scanning
Unless otherwise specified, to correct an error during a scanning sequence, just re-scan the correct parameter.
Imaging Preferences Parameter Defaults
Table 6-1 lists the defaults for imaging preferences parameters. To change the default values, scan the
appropriate bar codes in this guide. These new values replace the standard default values in memory. To recall
the default parameter values, scan the Default Parameters on page 5-5.
NOTE See Appendix A, Standard Default Parameters for all user preferences, hosts, symbologies, and
miscellaneous default parameters.
Table 6-1
Imaging Preferences Default Parameters
Parameter
Parameter
Number
Default
Page
Number
Imaging Preferences
Operational Modes N/A N/A 6-4
Image Capture Illumination 361 Enable 6-5
Gain / Exposure Priority for Snapshot
Mode
562 Autodetect 6-6
Snapshot Mode Timeout 323 0 (30 seconds) 6-7
Snapshot Aiming Pattern 300 Enable 6-7
Image Cropping 301 Disable 6-7
Crop to Pixel Addresses 315
316
317
318
0 top
0 left
479 bottom
751 right
6-8
Image Size (Number of Pixels) 302 Full 6-9
Image Brightness (Target White) 390 180 6-10
JPEG Image Options 299 Quality 6-10
JPEG Target File Size 561 160 kB 6-11
To Next Page
