Zebra DS6878 Product Reference Guide

CHAPTER 7 USB INTERFACE
Introduction
This chapter provides instructions for programming the cradle to interface with a USB host. The digital scanner
cradle connects directly to a USB host, or a powered USB hub. The USB host can power the cradle and
recharge the digital scanner battery, but this charging method has limitations. See Using the USB Interface to
Supply Power on page 1-9.
Throughout the programming bar code menus, default values are indicated with asterisks (
*).
*North American Standard USB Keyboard
Feature/Option
* Indicates Default
NOTE The CR0078-S cradle has the ability to be powered by the USB port instead of an external power supply.
The CR0078-P can only receive power via an external power supply.

Zebra DS6878 Specifications

General

Wavelength	655 nm
Scanner type	2D
Yaw reading angle	-60 - 60 °
Decoding standards	1D, 2D, PDF417, PDF417, microPDF417, Composite Codes (CC-A, CC-B, CC-C), U.S. Postnet and Planet, U.K., Japan, Australian, Netherlands KIX code, Royal Mail 4 State Customer, UPU ICS 4 State Postal, USPS 4CB, TL C-39, Aztec (Standard, Inverse), MaxiCode, DataMatrix/ECC 200 (Standard, Inverse), QR Code (Standard, Inverse and Micro)
Tilt reading angle	-360 - 360 °
Input voltage	5 V
Bluetooth	Yes
Dimensions (WxDxH)	69 x 97 x 185 mm
Certification	FCC, RoHS
Product color	Black
International Protection (IP) code	IP43
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Cables included	USB

Weight and Dimensions

Weight	238 g
