Zebra DS6878 Product Reference Guide

Getting Started 1 - 9
Supplying Power to the CR0078-S/CR0008-S Cradle
The CR0078-S/CR0008-S cradle receives power from one of two sources:
• An external power supply.
• When connected to the host through a host cable that supplies power (CR0078-S only).
The cradle detects whether the host or the external supply is supplying power. It always draws power from the
external supply when available, regardless of the presence of power from a host.
Using the USB Interface to Supply Power
When the CR0078-S cradle is connected to the host via the USB interface, it can be powered by the USB port
instead of an external power supply. Powering from a USB host limits charging. The digital scanner charges at
a slower rate than when charging from an external power supply.
Connecting the CR0078-P Series Cradle
Connect the interface cable and power supply (if necessary) in the following order to ensure proper operation of the digital
scanner and cradle:
1. Insert the interface cable into the cradle’s host port.
2.
Connect the other end of the interface cable to the host.
3. Connect the power supply to the cradle’s power port.
4. Connect the appropriate cable to the power supply and AC power source.
5.
Thread the interface cable over the cable support hook (see Figure 1-6 on page 1-6) and run the host and
power cables into their respective cable grooves.
IMPORTANT For healthcare environments, use cradle p/n CR0078-SC1009BWR and place the ferrite core
(included in box with cradle) on the power supply (refer to the Power Supply Ferrite Installation
instructions included in the box).
NOTE The radio link functions normally when the cradle draws power from a USB host.

Zebra DS6878 Specifications

General

Wavelength	655 nm
Scanner type	2D
Yaw reading angle	-60 - 60 °
Decoding standards	1D, 2D, PDF417, PDF417, microPDF417, Composite Codes (CC-A, CC-B, CC-C), U.S. Postnet and Planet, U.K., Japan, Australian, Netherlands KIX code, Royal Mail 4 State Customer, UPU ICS 4 State Postal, USPS 4CB, TL C-39, Aztec (Standard, Inverse), MaxiCode, DataMatrix/ECC 200 (Standard, Inverse), QR Code (Standard, Inverse and Micro)
Tilt reading angle	-360 - 360 °
Input voltage	5 V
Bluetooth	Yes
Dimensions (WxDxH)	69 x 97 x 185 mm
Certification	FCC, RoHS
Product color	Black
International Protection (IP) code	IP43
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Cables included	USB

Weight and Dimensions

Weight	238 g
