4 - 32 DS6878 Product Reference Guide
Secure Simple Pairing IO Capability (SPP Server and SPP Master Host Mode Only)
Bluetooth 2.1 uses the Secure Simple Pairing method to authenticate devices and create an encryption key. As
a part of that algorithm, the device must state its IO capabilities. When in Serial Profile Host (master or slave),
the default is No Input/No Output and no user interaction is required; however, a device may prompt the user
to confirm the pairing process.
Keyboard Only (passkey entry) is used between a device with a display and a device with numeric keypad
entry (such as a keyboard), or two devices with numeric keypad entry. In the first case, the display shows a
6-digit numeric code to the user, who then enters the code on the keypad. In the second case, the user of each
device enters the same 6-digit number.
• No Input/No Output: Least amount of security (may not be acceptable for some devices).
• Keyboard Only: Higher level of security.
NOTE Use this option to connect to an Android tablet.
* No Input/No Output
Keyboard Only

Zebra DS6878 Specifications

General

Wavelength	655 nm
Scanner type	2D
Yaw reading angle	-60 - 60 °
Decoding standards	1D, 2D, PDF417, PDF417, microPDF417, Composite Codes (CC-A, CC-B, CC-C), U.S. Postnet and Planet, U.K., Japan, Australian, Netherlands KIX code, Royal Mail 4 State Customer, UPU ICS 4 State Postal, USPS 4CB, TL C-39, Aztec (Standard, Inverse), MaxiCode, DataMatrix/ECC 200 (Standard, Inverse), QR Code (Standard, Inverse and Micro)
Tilt reading angle	-360 - 360 °
Input voltage	5 V
Bluetooth	Yes
Dimensions (WxDxH)	69 x 97 x 185 mm
Certification	FCC, RoHS
Product color	Black
International Protection (IP) code	IP43
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Cables included	USB

Weight and Dimensions

Weight	238 g
