5 - 2 DS6878 Product Reference Guide
Scanning Sequence Examples
In most cases scanning one bar code sets the parameter value. For example, to set the beeper tone to high,
scan the High Frequency (beeper tone) bar code listed under Beeper Tone on page 5-8. The digital scanner
issues a fast warble beep and the LED turns green, signifying a successful parameter entry.
Other parameters require scanning several bar codes. See these parameter descriptions for this procedure.
Errors While Scanning
Unless otherwise specified, to correct an error during a scanning sequence, just re-scan the correct parameter.
User Preferences/Miscellaneous Option Parameter Defaults
Table • lists the defaults for preferences parameters. To change the default values:
• Scan the appropriate bar codes in this guide. These new values replace the standard default values in
memory. To recall the default parameter values, scan the Default Parameters on page 5-5.
• Configure the digital scanner using the 123Scan
2
configuration program (see 123Scan2 on page 13-1).
NOTE See Appendix A, Standard Default Parameters for all user preferences, hosts, symbologies, and
miscellaneous default parameters.
Table 5-1 User Preferences Default Parameters
Parameter
Parameter
Number
Default
Page
Number
User Preferences
Set Default Parameter Set Defaults 5-5
Parameter Bar Code Scanning 236 Enable 5-6
Beep After Good Decode 56 Enable 5-6
Suppress Power Up Beeps 721 Do Not Suppress 5-7
Beeper Tone 145 Medium 5-8
Beeper Volume 140 High 5-9
Beeper Duration 628 Medium 5-10
Beep on Insertion 288 Enable 5-10
Decode Pager Motor 613 Disable 5-11
Decode Pager Motor Duration 626 150 msec 5-11
Night Mode Trigger 1215 Disable 5-14
Night Mode Toggle N/A N/A 5-14
Batch Mode 544 Normal (Do Not Batch
Data)
5-15

Zebra DS6878 Specifications

General

Wavelength	655 nm
Scanner type	2D
Yaw reading angle	-60 - 60 °
Decoding standards	1D, 2D, PDF417, PDF417, microPDF417, Composite Codes (CC-A, CC-B, CC-C), U.S. Postnet and Planet, U.K., Japan, Australian, Netherlands KIX code, Royal Mail 4 State Customer, UPU ICS 4 State Postal, USPS 4CB, TL C-39, Aztec (Standard, Inverse), MaxiCode, DataMatrix/ECC 200 (Standard, Inverse), QR Code (Standard, Inverse and Micro)
Tilt reading angle	-360 - 360 °
Input voltage	5 V
Bluetooth	Yes
Dimensions (WxDxH)	69 x 97 x 185 mm
Certification	FCC, RoHS
Product color	Black
International Protection (IP) code	IP43
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Cables included	USB

Weight and Dimensions

Weight	238 g
