Zebra WT6000 User Manual

Accessories
115
USB and Charging Cable
The USB and Charging cable connects to either interface connector on the WT6000. When attached to the
WT6000, allows the WT6000 to transfer data to a host computer and provide power for charging the WT6000.
Figure 107 USB and Charging Cable
Attaching the USB and Charging Cable
1. Connect the connector to the WT6000 interface connector.
Figure 108 Connecting Scanner to WT6000
2. Attach the USB connection to the host computer.
NOTE: Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines on page 128.
Power Connector
USB Connector
WT6000 Connector
Cable Connector
Interface Connector

Zebra WT6000 Specifications

General

Display diagonal	3.2 \
Display brightness	400 cd/m²
Display resolution	800 x 480 pixels
Gorilla Glass version	Gorilla Glass 3
Display number of colors	16.78 million colors
Flash memory	8 GB
Internal memory	2 GB
Internal memory type	-
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Number of cores	4
Processor frequency	1 GHz
Battery capacity	3350 mAh
GPS (satellite)	No
Operating system installed	Android
Product color	Black
International Protection (IP) code	IP65
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
Operating frequency	2412 - 2472, 5180 - 5835 MHz
Security algorithms	EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, MSCHAPv2, WEP, WPA-TKIP, WPA2-AES, WPA2-TKIP
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	34 mm
Width	121 mm
Height	89 mm
Weight	245 g
