Zebra WT6000 User Manual

Applications
71
Device Central
Device Central displays detailed information about the WT6000 and connected peripherals and supports the
following Zebra devices:
• RS507/RS507X Hands-free Imager
• RS6000 Bluetooth Ring Scanner
• RS5,000 Corded Ring Scanner
• HS3100 Bluetooth Headset
• DS3678 Digital Scanner.
Device Central features include:
• Discovering and pairing with supported peripherals via Bluetooth or corded connection.
• Paging a connected RS6000 Ring Scanner.
• Updating the firmware of supported ring scanners. For information on updating ring scanner firmware
using Device Central, refer to the RS5,000 Quick Start Guide or RS6000 User Guide.
• Displaying the connection status of peripherals.
• Displaying information for a connected peripheral in the notification bar.
Figure 58 Device Central Screen
Device Central Tabs
• Peripherals Tab - displays all currently connected and previously connected peripherals. Connected
peripherals display the length of time (in minutes) that they have been connected. When an RS6000 is
connected the Page button displays. See Paging an RS6000 Ring Scanner on page 71.
Touch the peripheral information to display the Device Details screen.
• Device Details - displays detailed device information for the selected peripheral.
• My Device Tab - displays information about the WT6000 and the current version of Device Central.
• Device Details - displays the About device screen.
• Device Battery Details - displays the Battery screen.
Paging an RS6000 Ring Scanner
Use the Page button to easily locate the currently connected RS6000 Ring Scanner:
1. With the RS6000 Ring Scanner connected, swipe up from the bottom of the screen.

Zebra WT6000 Specifications

General

Display diagonal	3.2 \
Display brightness	400 cd/m²
Display resolution	800 x 480 pixels
Gorilla Glass version	Gorilla Glass 3
Display number of colors	16.78 million colors
Flash memory	8 GB
Internal memory	2 GB
Internal memory type	-
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Number of cores	4
Processor frequency	1 GHz
Battery capacity	3350 mAh
GPS (satellite)	No
Operating system installed	Android
Product color	Black
International Protection (IP) code	IP65
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
Operating frequency	2412 - 2472, 5180 - 5835 MHz
Security algorithms	EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, MSCHAPv2, WEP, WPA-TKIP, WPA2-AES, WPA2-TKIP
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	34 mm
Width	121 mm
Height	89 mm
Weight	245 g
