Zebra WT6000 User Manual

Accessories
124
RS4000 Scanner
To connect the RS4000 scanner to the WT6000:
1. Connect the scanner interface cable to the WT6000 interface connector. If the WT6000 is mounted on the arm,
connect the cable to the interface connector closest to the wrist.
Figure 119 Connecting Scanner to WT6000
2. If using the extended cable configuration, route the scanner cable up to the shoulder and down to the hand that
the scanner mounts on. Attach two cable clips to clothing and secure cable to cable clip.
Figure 120 Cable Clip Installation
3. Rotate the trigger assembly to the correct position for the hand that the scanner mounts to.
4. Slide the scanner onto the index finger with the scan trigger next to the thumb.
NOTE: There are two scanner configurations available. The short cable configuration connects the scanner to the
WT6000 mounted on the arm. The extended cable configuration connects the scanner to the WT6000 mounted on
the hip.
Cable Connector
Interface Connector

Zebra WT6000 Specifications

General

Display diagonal	3.2 \
Display brightness	400 cd/m²
Display resolution	800 x 480 pixels
Gorilla Glass version	Gorilla Glass 3
Display number of colors	16.78 million colors
Flash memory	8 GB
Internal memory	2 GB
Internal memory type	-
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Number of cores	4
Processor frequency	1 GHz
Battery capacity	3350 mAh
GPS (satellite)	No
Operating system installed	Android
Product color	Black
International Protection (IP) code	IP65
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
Operating frequency	2412 - 2472, 5180 - 5835 MHz
Security algorithms	EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, MSCHAPv2, WEP, WPA-TKIP, WPA2-AES, WPA2-TKIP
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	34 mm
Width	121 mm
Height	89 mm
Weight	245 g
