Getting Started
17
Starting the WT6000
When installed in a cradle, the WT6000 starts automatically as soon as power is applied.
When a charged battery is installed and the WT6000 is turned off, press the Power button to turn on.
When the WT6000 is powered on for the first time, it initializes its system. The splash screen appears for a short
period of time.
Figure 5 Splash Screen
The splash screen is followed by the boot animation screen and then the Home Screen.
Figure 6 Home Screen
Table 3 Charge LED Charging Indicators
State Indication
Off WT6000 is not charging. WT6000 is not inserted correctly in the cradle or
connected to a power source. Charger/cradle is not powered.
Solid Amber Healthy battery is charging.
Solid Green Healthy battery charging is complete.
Fast Blinking Red
(2 blinks/second)
Charging error, e.g.:
- Temperature is too low or too high.
- Charging has gone on too long without completion (typically eight hours).
Solid Red Unhealthy battery is charging or fully charged.
IMPORTANT: When trying to power on the device, a quick red blink of the Charging LED indicates that it does not
have enough battery power to turn on. Charge the battery or replace it.
