318 Appendix C Procedure to Lock Out Front/Rear Terminals and Guard Terminal Switches
Covers Installation
Procedure
Do the following:
1. Turn the 3458 over so its top sits on your workbench.
2. Install the bottom cover by placing it into the slots of the instrument side
castings, Then push the cover toward the front of the instrument into the
front panel bezel.
3. Turn the 3458 over so the bottom sits on your workbench.
4. Install the top cover by placing it into the slots of the instrument side
castings. Then push the cover toward the front of the instrument into the
front panel bezel.
5. Refer to Figure 38. Turn the instrument so its back faces you.
6. Reinstall the rear bezel. Use the #TX15 Torx driver to reinstall the rear
bezel screws.
7. Refer to Figure 37. Turn the instrument so its left side faces you. Use the
#TX10 Torx driver to reinstall the top and bottom covers ground screws.
WARNING For safety purposes and proper operation, it is very imperative
that the cover grounding screws be reinstalled.
8. Refer to Figure 36. Reinstall the left side handle strap. Use the #1 pozidriv
to reinstall side handle strap screws.
9. Refer to Figure 35. Turn the instrument so its right side faces you.
10.Reinstall the right side handle strap. Use the #1 pozidriv to reinstall side
handle strap screws.
11.Your instrument is now ready for use. Agilent suggests that after you apply
power that you perform an automatic calibration on the instrument. To do
this. use the "ACAL ALL" command.
