294 Appendix A Specifications
Settling Characteristics
For first reading or range change error using default delays, add .01% of input step additional error for the 100
µA to 100 mA ranges. For the 1 A range add .05% of input step additional error.
The following data applies for DELAY 0.
Maximum Input
6 / Frequency/ Period
Frequency / Period Characteristics
Accuracy
Function ACBAND Low DC Component Settling Time
ACI
³10 Hz DC < 10% AC 0.5 sec to 0.01%
DC > 10% AC 0.9 sec to 0.01%
ACDCI 10 Hz – 1 kHz 0.5 sec to 0.01%
1 kHz – 10 kHz 0.08 sec to 0.01%
³10 kHz 0.015 sec to 0.01%
Rated lnput Non-Destructive
I to LO ± 1.5 A pk < 1.25A rms
LO to Guard ± 200 V pk ± 350 V pk
Guard to Earth ± 500 V pk ± 1000 V pk
Voltage (AC or DC Coupled)
ACV or ACDCV Functions
1
Current (AC or DC Coupled)
ACI or ACDCI Functions
1
Frequency Range 1 Hz – 10 MHz 1 Hz – 100 kHz
Period Range 1 sec – 100 ns 1sec – 10 µs
Input Signal Range 700 V rms – 1 mV rms 1 A rms – 10 µA rms
Input Impedance 1 MW±15% with<140 pF
0.1 – 730 W
2
Range
24 Hour- 2 Year
0°C-55°C
1 Hz–40 Hz
1 s–25 ms 0.05% ofReading
40 Hz – 10 MHz
25 ms–100 ns .01% ofReading
Measurement Technique: Trigger Filter:
Reciprocal Counting Selectable 75 kHz Low Pass Trigger Filter
Time Base:
Slope Trigger:
10 MHz ± 0.01%, 0°C to 55°C
Positive or Negative
Level Trigger:
±500% of Range in 5% steps
Reading Rates
Resolution
Gate Time
3
Readings/sec
4
0.00001% 1 s 0.95
>0.0001% 100 ms 9.6
> 0.001% 10 ms 73
> 0.01% 1 ms 215
> 0.1% 100 µs 270
1. The source of frequency
measurements and the
measurement input
coupling are determined by
the FSOURCE command.
2. Range dependent, see ACI
for specific range
impedance values.
3. Gate Time is determined
by the specified
measurement resolution.
4. For Maximum Input
specified to fixed range
operation. For auto range,
the maximum speed is 30
readings/sec for ACBAND
³ 1 kHz.
Actual Reading Speed is
the longer of 1 period of
the input, the chosen gate
time, or the default reading
time-out of
1.2 sec.
