Alienware Area-51 m7700 User Manual

Upgrading The Computer
Upgrading the Optical (CD/DVD) Device(s) 6 - 9
6
Upgrading the Optical (CD/DVD) Device(s)
1. Turn off the computer, and turn it over and remove the battery.
2. Locate the hard disk bay cover and remove screws
- , and remove
the bay cover.
3. Remove screw
and use the screwdriver to push the optical device(s) out
of the computer at point .
Figure 6 - 6
Removing the CD/
DVD Device(s)
1 4
5
6
1
3
4
2
5
6

Alienware Area-51 m7700 Specifications

General

Operating System	Windows XP
Battery	12-cell Lithium-Ion
Processor	Intel Pentium 4
Graphics	NVIDIA GeForce Go 6800
Display	17-inch WUXGA
Memory	Up to 4GB DDR2
Storage	Up to 200GB HDD
Optical Drive	DVD±RW
Weight	5.4 kg (9.9 lbs)
