Specifications
D - 2
D
Feature Specification
Processor Types Intel® Pentium® 4 520/ 530/ 540/ 550/ 560/ 570 Processor with HT Technology
LGA775 Package (775-pin)
(90nm) 90 Nanometer Process Technology, 1024KB On-Die L2 Cache & 800MHz Front Side
Bus - 2.8/ 3.0/ 3.2/ 3.4/ 3.6/ 3.8 GHz
Core Logic Intel 915P + ICH6
Security Security (Kensington® Type) Lock Slot BIOS Password
Memory Two 64-bit wide DDR-II (DDR2) Data Channels
Four 200 Pin DDR-II (DD2) SODIMM Sockets
Expandable up to 4GB (Compatible with 1024MB, 512MB, 256MB DDR-II (DDR2) - 400/ 533
Modules)
BIOS One 512KB Flash ROM Phoenix BIOS
LCD 17" WXGA (1440 * 900) / WSXGA+ (1680 * 1050) / WUXGA (1920 * 1200) TFT LCD
Memory Available
Even if you have 4GB of RAM in the computer, the POST (at Startup) or System (Win-
dows) Control Panel, will show 2814GB of RAM available to the system. This is due to
1GB of RAM being reserved for the PCI space, and some RAM also being reserved for
the BIOS.
