Alienware Area-51 m7700 User Manual

1 - 12 System Map: Bottom View
Quick Start Guide
1
System Map: Bottom View
Figure 1 - 7 - Bottom View
1. Battery
2. Vent/Fan Intake
3. Memory (RAM) Cover
4. Hard Disk Cover
5. Sub Woofer
6. Video Card Cover
7. CPU Cover
2
1
2
2
4
2
3

CPU
The CPU is not a user
serviceable part.
Opening this compart-
ment, or accessing the
CPU in any way, may
violate your warranty.

Battery Information
Always completely discharge, then fully charge, a new battery before using it. Completely discharge and charge the battery
at least once every 30 days or after about 20 partial discharges. See “Battery Information” on page 3 - 9 for full instruc-
tions.
5
6
7

Alienware Area-51 m7700 Specifications

General

Operating System	Windows XP
Battery	12-cell Lithium-Ion
Processor	Intel Pentium 4
Graphics	NVIDIA GeForce Go 6800
Display	17-inch WUXGA
Memory	Up to 4GB DDR2
Storage	Up to 200GB HDD
Optical Drive	DVD±RW
Weight	5.4 kg (9.9 lbs)
