170 Rockwell Automation Publication 2080-UM002K-EN-E - March 2019
Chapter 9 Controller Security
6. Click Download.
7. Click Disconnect.
Transfer Controller Program and Password-Protect Receiving
Controller
In this scenario, the user needs to transfer user application from controller1
(locked) to another Micro800 controller with the same catalog number. The
transfer of the user application is done through the Connected Components
Workbench software by uploading from controller1, then changing the target
controller in the Micro800 project, and then downloading to controller2. Finally,
controller2 will be locked.
1. In the Project Organizer, click the Discover icon.
The Browse Connections dialog appears.
2. Select target controller1.
3. When requested, enter the controller password for controller1.
4. Build and save the project.
5. Click Disconnect.
6. Power down controller1.
7. Swap controller1 hardware with controller2 hardware.
8. Power up controller2.
9. Click Connect.
10. Select target controller2.
11. Click Download.
12. Lock controller2. See Configure Controller Password
on page 261.
If the controller has a password locked revision 10 or later project, you
cannot access the controller using Connected Workbench software
revision 9 or earlier. If you use Connected Components Workbench
software revision 10 or later to download a revision 9 or earlier project,
the password in the controller will be automatically converted to the
old algorithm.
If the controller has a password locked revision 9 or earlier project and
you use Connected Components Workbench software revision 10 or later,
to download a revision 10 or later project, the password in the controller
will be automatically converted to the new algorithm.
If communication is lost during the download, repeat the download and
verify that the controller is password protected.
