Rockwell Automation Publication 2080-UM002K-EN-E - March 2019 219
Specifications Appendix A
For the Micro830 controller relay chart, see Relay Chart for Micro830,
Micro850, and Micro870 Controllers on page 234.
Environmental Specifications
Surge current, per point Refer to Relay Contacts Ratings on
page 219
4.0 A every 1 s @ 30 °C; every 2 s @ 65 °C
(1)
Current, per common, max 5 A — —
Turn on time/
Turn off time, max
10 ms 2.5 µsON: 0.1 ms
OFF: 1 ms
(1) Applies for general purpose operation only. Does not apply for high-speed operation.
Outputs
Attribute 2080-LC30-48AWB,
2080-LC30-48QWB
2080-LC30-48QVB, 2080-LC30-48QBB
Relay Output Hi-Speed Output
(Outputs 0…3)
Standard Output
(Outputs 4 and higher)
Relay Contacts Ratings
Maximum Volts Amperes Amperes
Continuous
Volt-Amperes
Make Break Make Break
120V AC 15 A 1.5 A 2.0 A 1800V A 180V A
240V AC 7.5 A 0.75 A
24V DC 1.0 A 1.0 A 28V A
125V DC 0.22 A
Environmental Specifications
Attribute Value
Temperature, operating IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20…65 °C (-4…149 °F)
Temperature, surrounding air, max 65 °C (149 °F)
Temperature, nonoperating IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal
Shock):
-40…85 °C (-40…185 °F)
Relative humidity IEC 60068-2-30 (Test Db, Unpackaged Damp Heat):
5…95% non-condensing
Vibration IEC 60068-2-6 (Test Fc, Operating):
2 g @ 10…500 Hz
Shock, operating IEC 60068-2-27 (Test Ea, Unpackaged Shock):
25 g
Shock, nonoperating IEC 60068-2-27 (Test Ea, Unpackaged Shock):
DIN mount: 25 g
PANEL mount: 35 g – 24-point and 48-point controllers
45 g – 10-point and 16-point controllers
