Rockwell Automation Publication 2080-UM002K-EN-E - March 2019 201
Using microSD Cards Chapter 10
3. From the Upload window that appears, select the date of the data log files
that you would like to upload. You can upload data logs for the entire
month by clicking Whole Month option button.
4. If the file already exists in your destination folder, select whether you
would like to Overwrite file, Skip file, or Preserve both files.
5. Click Upload. The progress bar should tell you whether the upload is
successful or not.
Do not take out the microSD card from the slot while data is being
written or retrieved from the card. Ongoing write and retrieval operations
are indicated by a flashing SD status LED.
For better data log file management, you can use a third-party tool or
DOS CMD to merge all your data log files into a single file and import as
a CSV file in Excel.
