Allen-Bradley Micro830 User Manual

210 Rockwell Automation Publication 2080-UM002K-EN-E - March 2019
Appendix A Specifications
Power supply voltage range 20.4…26.4V DC Class 2
I/O rating Input:
24V DC, 8.8 mA
Output:
2 A, 240V AC, general use
Input:
24V DC, 8.8 mA
Output:
2 A, 24V DC, 1 A per point
(Surrounding air temperature 30 °C)
24 V DC, 0.3 A per point
(Surrounding air temperature 65 °C)
Isolation voltage 250V (continuous), Reinforced Insulation Type, Outputs to
Aux and Network, Inputs to Outputs
Type tested for 60 s @ 720V DC, Inputs to Aux and
Network, 3250 V DC Outputs to Aux and Network, Inputs to
Outputs
50V (continuous), Reinforced Insulation Type, I/O to Aux
and Network, Inputs to Outputs
Type tested for 60 s @ 720V DC, I/O to Aux and Network,
Inputs to Outputs
Pilot duty rating C300, R150 —
Insulation stripping length 7 mm (0.28 in.)
Enclosure type rating Meets IP20
North American temp code T4
(1) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
General Specifications
Attribute 2080-LC30-10QWB 2080-LC30-10QVB
Inputs
Attribute 2080-LC30-10QWB, 2080-LC30-10QVB
High-Speed DC Input
(Inputs 0…3)
Standard DC Input
(inputs 4 and higher)
Number of Inputs 4 2
Input group to backplane
isolation
Verified by one of the following dielectric tests: 1,414V DC for 2 s
75V DC working voltage (IEC Class 2 reinforced insulation)
Voltage category 24V DC sink/source
Off-state voltage, max 5V DC
On-state voltage, nom 24V DC
On-state voltage range 16.8…26.4V DC @ 65 °C (149 °F)
16.8…30.0V DC @ 30 °C (86 °F)
10…26.4V DC @ 65 °C (149 °F)
10…30.0V DC @ 30 °C (86 °F)
Off-state current, max 1.5 mA
On-state current, min 5.0 mA @ 16.8V DC 1.8 mA @ 10V DC
On-state current, nom 8.8 mA @ 24V DC 8.5 mA @ 24V DC
On-state current, max 12.0 mA @ 30V DC
Nominal impedance 3 kΩ 3.74 kΩ
IEC input compatibility Type 3
AC input filter setting 8 ms for all embedded inputs
(In Connected Components Workbench, go to the Embedded I/O configuration window to reconfigure the filter setting for
each input group)
