20 Rockwell Automation Publication 2080-UM002K-EN-E - March 2019

Chapter 2 About Your Controller

RMCC EtherNet/IP Example – Set the Parameters

RMCC EtherNet/IP Example – Set the New IP Address

For this example, the new IP Address is set to the following:

• IP address = 192.168.1.10

• Subnet mask = 255.255.255.0

• Gateway address = 192.168.1.1

RMCC EtherNet/IP Example – Set the Message Length

Attribute 5

ReqData IP address, Subnet mask, Gateway address

ReqLen 22 bytes

CIP Generic Message Parameters for RMCC using EtherNet/IP
