34 Rockwell Automation Publication 2080-UM002K-EN-E - March 2019

Chapter 3 Install Your Controller

Micro830 24-Point Controllers

2080-LC30-24QWB, 2080-LC30-24QVB, 2080-LC30-24QBB

Micro830 48-Point Controllers

2080-LC30-48AWB, 2080-LC30-48QWB, 2080-LC30-48QVB,

2080-LC30-48QBB

45018

150 (5.91)

80 (3.15)

90 (3.54)

Measurements in millimeters (inches)

45038

210 (8.27)

80 (3.15)

90 (3.54)

Measurements in millimeters (inches)
