38 Rockwell Automation Publication 2080-UM002K-EN-E - March 2019

Chapter 3 Install Your Controller

Micro850 24-Point Controllers

2080-LC50-24AWB, 2080-LC50-24QBB, 2080-LC50-24QVB, 2080-LC50-24QWB

Micro870 24-Point Controllers

2080-LC70-24AWB, 2080-LC70-24QWB, 2080-LC70-24QWBK,

2080-LC70-24QBB, 2080-LC70-24QBBK

Micro830 48-Point Controllers

2080-LC30-48AWB, 2080-LC30-48QWB, 2080-LC30-48QVB,

2080-LC30-48QBB

45913

131 mm (5.16 in.)

100 mm (3.94 in.)

45917

108 mm (4.25 in)

100mm

(3.9 in)

Default Chapter3
