84 Rockwell Automation Publication 442L-UM005B-EN-P - April 2017
Chapter 11 Technical Specifications
OSSD Response Times
The total response time of your application is dependent on:
• The basic response time of the SafeZone Mini device.
• The multiple sampling set.
• The OSSDs that are used.
Calculate the Total Response Time T
S
:
T
S
= t
B
+ T
MFA
Multiple Sampling
On the SafeZone Mini device at least double multiple sampling is always set.
For a multiple sampling of three or higher, you must add a supplement of 80 ms
to the basic response time.
Table 16 - Multiple Sampling Supplements
Variable Description
t
B
Basic response time = 80 ms
T
MFA
Supplement due to multiple sampling > 2
Multiple Sampling Supplement
Basic Response Time + Supplement
2 times (basic setting) 0 ms 80 ms
3 times 40 ms 120 ms
4 times 80 ms 160 ms
5 times 120 ms 200 ms
6 times 160 ms 240 ms
7 times 200 ms 280 ms
8 times 240 ms 320 ms
9 times 280 ms 360 ms
10 times 320 ms 400 ms
11 times 360 ms 440 ms
12 times 400 ms 480 ms
13 times 440 ms 520 ms
14 times 480 ms 560 ms
15 times 520 ms 600 ms
16 times 560 ms 640 ms
