Technical Specifications Chapter 11
Electrical Specifications
Table 21 - Electrical Specifications
Table 22 - Universal I/O Specifications
Attribute 442L-SFZNMN
Supply voltage (SELV)
(1)
(2)
(1) To meet the requirements of the relevant product standards (for example, EN 61496-1), the external voltage supply for the
device must be able to bridge a brief mains failure of 20 ms. Power supplies according to EN 60204-1 satisfy this requirement.
Suitable power supplies are available as accessories from Rockwell Automation.
(2) Operation only in a short-circuit protected system with max. 8 A
16.8…30 V (24V, typical)
Permissible residual ripple
(3)
(3) The absolute voltage level must not drop below the specified minimum voltage.
±5%
Switch on current
(4)
(4) The load currents for the input capacitors are not considered.
2.0 A
Operating
current without
output load
2 m (6.56 ft) SafeZone Mini Device 0.16 A (0.20 A, max)
(5)
(5) With the typical supply voltage of 24V.
3 m (9.84 ft) SafeZone Mini Device 0.18 A (0.25 A, max)
(5)
Operating
current with
max output load
2 m (6.56 ft) SafeZone Mini Device 1.35 A
(5)
3 m (9.84 ft) SafeZone Mini Device 1.35 A
(5)
Power
consumption
without output
load
2 m (6.56 ft) SafeZone Mini Device 3.9 W (4.8 W, max)
(5)
3 m (9.84 ft) SafeZone Mini Device 4.4 W (6.0 W, max)
(5)
Power
consumption
with max output
load
2 m (6.56 ft) SafeZone Mini Device 33 W
3 m (9.84 ft) SafeZone Mini Device 33 W
Power
consumption in
the stand-by
mode or park
mode without
output load
2 m (6.56 ft) SafeZone Mini Device 3.6 W (4.8 W, max)
3 m (9.84 ft) SafeZone Mini Device 4.4 W (6.0 W, max)
Electrical connection Connecting cable with round plug connector
Cable length for power supply tolerance ±10% 25 m (82.0 ft)
Cable length for power supply tolerance ±5% 34 m (111.5 ft)
Cable length for power supply tolerance ±1% 40 m (131.2 ft)
Attribute 442L-SFZNMN
Input resistance when HIGH 2 Ω
Voltage for HIGH 11…30V (24V, typical)
Voltage for LOW -3…+5V (0V, typical)
Input capacitance 15 nF
Static input current 6…15 mA
Actuating time of the control switch for restart 120…200 ms
HIGH switching voltage at 100 mA V
S
– 3.3 V…V
S
Source switching current 100…200 mA
Current limiting (after 5 ms at 25 °C [77 °F]) 600…920 mA
Power up delay 1.4…2 ms
Switch off delay 0.7…2 ms
Response time with configuration as second warning
field output
Corresponds to the resulting response time of the OSSDs
plus 50 ms
