Allen-Bradley SafeZone Mini User Manual

Rockwell Automation Publication 442L-UM005B-EN-P - April 2017 91
Technical Specifications Chapter 11
Dimension Drawings
The measurements in the following drawings are in millimeters (inches).
SafeZone Mini Safety Laser Scanner
Figure 54 - SafeZone Mini Device [mm (in.)]
94 (3.7) dia.
116
(4.57)
79.7
(3.14)
43.3
(1.70)
102 (4.02) dia.
73 (2.87) dia.
36.5
(1.44)
200 (7.87) max.
104 (4.09)
54.5
(2.15)
23.8
(0.94)
36.4
(1.43)
Min. 15
Min. 15
M5 x 7.5
10.5 (0.41)
250 (9.84)
43.3
(1.70)
5
(0.20)
