ENGINE
RS 125
6.1. EXHAUST SYSTEM
6.1.1. EXHAUST PIPE REMOVAL
TORQUE WRENCH SETTINGS
Screws (1-2) 22 Nm (2.2 Kgm)
Screw (3) 20 Nm (2.0 Kgm)
• Remove both side fairings; see
7.1.2.
• Remove the fairing air dam; see
7.1.3.
• Unhook the two springs from the exhaust flange on the
cylinder.
• Release and remove the screw (1) and collect the two
washers and the nut.
• Release and remove the screw (2) on the left-hand
passenger footpeg bracket and collect the washer and
the nut.
• Remove the exhaust pipe together with its clamp.
If needed, remove the exhaust flange as follows:
• Release and remove the two screws (3) and collect
the lap plate.
• Remove the exhaust flange and collect the seal (4).
WARNING
On refitting, use a new exhaust flange seal (4)
and check that the mounting brackets (5) are
correctly positioned.
6 - 3

APRILIA RS 125 Specifications

General

Displacement	124.8 cc
Transmission	6-speed
Front Suspension	Upside-down fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Dry Weight	114 kg
Fuel System	Carburetor
Frame	Aluminum perimeter frame
Engine Type	Single cylinder, 2-stroke
