ROUTINE MAINTENANCE
RS 125
2.15.3. COLD-START CABLE PLAY
ADJUSTMENT
There should be 2-3 mm free play in the cold-start cable.
Play is adjusted as follows:
• Place the motorcycle on the stand.
• Lift the fuel tank; see
2.9.1.
• Adjust working from the left side of the motorcycle.
NOTE DO NOT disturb the rubber gaiter of the throttle cable
(1).
• Slip off the rubber gaiter (2).
• Slacken the nut (3).
• Work the adjuster (4) located on the carburetor.
• When finished:
• Tighten the nut (3) to lock the adjuster (4) and refit the
rubber gaiter (2).
3
4
2
1
2 - 42
