CHASSIS
7 - 5
RS 125
39
40414243
30
38 37
36
35
34
33
322827 29262524
45
44
31
24. Engine Control Unit
25. Rear brake master cylinder
26. Rider seat
27. Air cleaner
28. Right-hand seat subframe cover
29. Coolant expansion reservoir
30. Battery
31. Front brake fluid reservoir
32. Right rearview mirror
33. Front fairing
34. Right body panel
35. Front wheel
36. Front brake disc
37. Front brake caliper
38. Rear brake fluid reservoir
39. Rear shock absorber
40. Rear brake lever
41. Right rider footpeg
42. Drive chain
43. Rear swinging arm
44. Rear wheel
45. Right passenger footpeg (spring-loaded, snaps open/closed)
