APRILIA RS 125 User Manual

CHASSIS
7 - 104
RS 125
• Position the linkages to the swinging arm.
• Insert the screw from the right-hand side.
• Position the washer and tighten the nut (5).
• Route the brake hose along the swinging arm.
• Secure the brake hose inner clip with the screw (6).
• Secure the brake hose outer clip with the screw (7).
• Install the rear wheel; see
7.6.6
• Install the drive chain; see
7.13.2.
• Lower the hoist arm.
• Disconnect the slings from the frame.
• Install the fuel tank; see
4.1.1

APRILIA RS 125 Specifications

General

Displacement	124.8 cc
Transmission	6-speed
Front Suspension	Upside-down fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Dry Weight	114 kg
Fuel System	Carburetor
Frame	Aluminum perimeter frame
Engine Type	Single cylinder, 2-stroke
