APRILIA RS 125 User Manual

ELECTRICAL SYSTEM
8 - 20
RS 125
LIGHT DIP SWITCH TEST
Check for continuity across the contacts using a multimeter
set to the ohm range. Please refer to the relevant diagram.
V/N G/N V G
R G/R R/N
START OFF
RH DIP SWITCH
LH DIP SWITCH
Az R V/N
Bi
Gr B
N
G/N
B/N
PASSING
V/N V
R G/R R/N
START OFF
RH DIP SWITCH-
ADS VERSION

APRILIA RS 125 Specifications

General

Displacement	124.8 cc
Transmission	6-speed
Front Suspension	Upside-down fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Dry Weight	114 kg
Fuel System	Carburetor
Frame	Aluminum perimeter frame
Engine Type	Single cylinder, 2-stroke
