Arris CHP Max5000 User Manual

Rev D CHP Max DC Power Supply 5-1
CHAPTER 5
CHP MAX DC POWER SUPPLY
The following table lists the minimum revision level to enable all features of this module to
work properly. If you are installing a module and have a later revision, all functions are
compatible unless stated otherwise in the release notes. On occasion, a function may be
removed.
This chapter provides physical and functional descriptions of the CHP Max DC Power Supply
module.
Equipment Description —page 5-2
Connectors—page 5-3
Functional Description—page 5-4
Installing/Removing the Power Supply Module—page 5-5
DC Power Supply Specifications—page 5-18
Module P/N Craft Management S/W
Rev
SMM F/W Rev CMM F/W Rev
CHP-PS/DC1 5.0.4 1.1.0.0 3.002
CHP-PS/DC1-Q 5.0.27 1.6.0.0 3.006
CHP-PS/DC1-SW N/A 4.0.0.0 4.033

Arris CHP Max5000 Specifications

General

Brand	Arris
Model	CHP Max5000
Category	Multi-service Platforms
Language	English
