Arris CHP Max5000 User Manual

B-12 CHP Max™ Headend Optics Platform Chassis, Controllers and Power Supplies 1508685 Rev D
CHP HMS Values
Controller Cards
Note The indexes in the following tables are shown for a chassis that has a CMM
address of 500.
cmm cards / Index 14
heCommonLogOID MIB heCommonLogText
1.3.6.1.4.1.2907.20.2.1.3.1
.1.1.2.50014.1
.iso.org.dod.internet.private.enterp
rises.ccor-reg-ident.ccorHeadend.c
corHeadendMIB.chpMax5000MIB.c
hpCmmMIB.cmmMIBObjects.cmm
ParamTable.cmmParamEntry.cmm
ParamVoltage.50014.1
Backplane +12VDC Alarm
Backplane +5VDC Alarm
Backplane +3.3VDC Alarm
Backplane -5VDC Alarm
1.3.6.1.4.1.5591.1.11.2.1.1
.1.1.1.1.2.50014
.iso.org.dod.internet.private.enterp
rises.scteRoot.scteHmsTree.insideP
lantIdent.heBaseIdent.heCommon.
heCommonMib.heCommonObjects
.heCommonParams.heCommonTa
ble.heCommonEntry.heCommonTe
mperature.50014
CMM Internal Temperature Alarm
1.3.6.1.4.1.2907.20.2.1.1.1
.2.2.1.1.50014
.iso.org.dod.internet.private.enterp
rises.ccor-reg-ident.ccorHeadend.c
corHeadendMIB.chpMax5000MIB.c
hpCommonMIB.chpCommonMIBO
bjects.chpMaxSlots.chpSlotStatusT
able.chpSlotStatusEntry.chpSlotStat
usPhysicalState.50014
Module Communication Status
Down
Module Removed
Module Communication Status
SMM cards / Index 15
heCommonLogOID MIB heCommonLogText
1.3.6.1.4.1.5591.1.11.2.1.1
.1.1.1.1.2.50015
.iso.org.dod.internet.private.enterp
rises.scteRoot.scteHmsTree.insideP
lantIdent.heBaseIdent.heCommon.
heCommonMib.heCommonObjects
.heCommonParams.heCommonTa
ble.heCommonEntry.heCommonTe
mperature.50015
SMM Internal Temperature Alarm
1.3.6.1.4.1.2907.20.2.1.1.1
.2.2.1.1.50015
.iso.org.dod.internet.private.enterp
rises.ccor-reg-ident.ccorHeadend.c
corHeadendMIB.chpMax5000MIB.c
hpCommonMIB.chpCommonMIBO
bjects.chpMaxSlots.chpSlotStatusT
able.chpSlotStatusEntry.chpSlotStat
usPhysicalState.50015
Module Communication Status
Down
Module Removed
Module Communication
