7-44 CHP Max™ Headend Optics Platform Chassis, Controllers and Power Supplies Rev D
Power Supply and Fan Module Slots
SMM-2 Controller Module
CHP Trap Information
Refer to Appendix B for information on the CHP Traps.
Table 7.4 Slot-Hardware-MIB Associations for Power Supply (slots 11 and 12) and Fan Bay (slot
13)
CHP Shelf
Virtual Slot
index
Possible
Hardware
Types
Supported IETF
Objects
Supported HMS
Objects
Supported ARRIS
Objects
Slots
11 (upper) or
12 (lower)
DC Power
Supply / AC
Power Supply
entPhysicalTable hePsMIBObjects
hePsOutputTable
hePsUnitTable
chpCommonMIB
chpSlotConfigTabl
e
chpSlotStatusTable
chpPsMIB
psStatusTable
Slot 13 Fans entPhysicalTable heCommonTable
heFanMIBObjects
heFanStatusTable
heFanUnitTable
chpCommonMIB
chpSlotConfigTabl
e
chpSlotStatusTable
Table 7.5 Slot-Hardware-MIB Associations for Controller Module
CHP
Shelf
Virtual
Slot
index
Possible
Hardware
Types
Supported IETF
Objects
Supported HMS
Objects
Supported ARRIS
Objects
Slot 15
Electrical
SMM-2 entPhysicalTable
systemMIB
snmpDomains
snmpModules
snmpMIB
snmpFramework
snmpMPDMIB
snmpTargetObjects
snmpTargetAddrTable
snmpTargetParamsTa
ble
snmpNotifyTable
heCommonTable
heCommonLog
chpCommonMIB
chpSlotConfigTable
chpSlotStatusTable
CHPSMM-MIB
smmParamTable
smmControlTable
smmStatusTable
smmSubratedTable
