12.3.8 DMS
1
Name
This eld enables to assign an individual name to the DMS microphone, other than the generic name assigned by the congurator.
2
Audio Inputs
The Audio Inputs eld contains all available audio inputs in the zone microphone. Item 1 on the above gure, is a gooseneck
condenser microphone – connected to the built in XLR socket.. As standard, adding a zone microphone sets the gooseneck
microphone using the built in XLR as activates the main microphone. Item 2 is a jack TRS 3.5mm type socket located on the
ABT-DMS rear panel, intended for electret microphones. The system automatically detects a microphone connected to the TRS
jack and disconnects the built in XLR in this event. Items 3,4,5,6 are four unbalanced linear audio inputs. Available via 3,5mm
TRS jack sockets. In one jack 3,5mm socket we have access to 2 channels – Tip: Channel 1+, Ring: Channel 2+, Sleeve 1,2. In
order to activate the input, in the Type window change the value Inactive into Line IN on the selected input which we want
to activate. Double-clicking the name of the audio input enables to change the generic name assigned by the congurator.
3
Audio Outputs – Local Output
Each zone microphone is equipped with two audio outputs. Item 1 is an output directly connected to the internal amplier
of the built-in speaker. Item 2 is a linear output, socket type TRS. Tip: out2+, Ring: out2+, Sleeve 2-. In order to activate the
output, in the Connection window change the value from Not connected into Line output. An activated output is shown as
a separate subzone in the system.
