6.2.3 ABT-DMS-LCD – zone microphone with LCD
For intuitive and easier operation, ABT-DMS-LCD has been equipped with a touch-screen display. Navigation in the menu
and change of settings is possible by means of both control buttons located next to LCD display, and touch-screen display.
ABT-DMS-LCD can only be used for purposes not related to evacuation/ alarm.
Zone microphone is equipped with intercom function which provides two-way communication between the zone microphones.
ABT-DMS-LCD has 4 local audio inputs on board and 1 audio output which allows for further system extension. Communication
with control units takes place via Ethernet 10/100BASE -TX, 1 LAN port.
Main features:
» 4,5” LCD touch screen for fast and clear matricing and system management
» Four non-symmetrical audio inputs, (1/8”) stereo jack connector
» Built-in speaker
» Stereo jack sockets for Headset / Audio out
» Implemented intercom function
» Extension up to ve 20-button modules
» Power supply via POE or locally 48VDC
13.
Drawing 26. Zone microphone with ABT-DMS-LCD display
