18
COMPACT VOICE ALARM SYSTEM
SERVICE MANUAL
6. Device description
This section provides an insight into AutroVoice miniVES system components:
» Control units
» Extension cards
» Microphones and microphone extensions
6.1 Internal devices
6.1.1 Control units
A control unit is the main element of the system which receives audio signal and sends it to the entire system. This device manages
all other elements. This component allows exible conguration of audio signal tracks from any source of signal to any output.
Global audio track switch is possible on the basis of the programmable logic system and Ethernet 1G (UDP/IP,TCP/IP) network.
AutroVoice miniVES system oers thirteen various control units:
» AutroVoice miniVES 2001 unit
to be used as a secondary unit or for smaller site applications. Unit equipped with a sigle xCtrLine-4 card
and a basic xNET_mini card
» AutroVoice miniVES 2001N unit
similar to the 2001 unit, additionaly equipped with the xNET_mini 1GB/WAN/RS card with extended networking capabilities
» AutroVoice miniVES 2001L unit
primary system unit, equipped with an LCD screen
» AutroVoice miniVES 2001LN unit
similar to the 2001L unit with the addition of the xNET_mini 1GB/WAN/RS card with extended networking capabilities
» AutroVoice miniVES 4001 unit
to be used as a secondary unit or for smaller site applications. Equipped with two xCtrLine-4 cards and a basic xNET_mini card
» AutroVoice miniVES 4001N unit
similar to the 4001 unit, additionaly equipped with the xNET_mini 1GB/WAN/RS card with extended networking capabilities
» AutroVoice miniVES 4001L unit
primary system unit, equipped with an LCD screen and two xCtrLine-4 cards
» AutroVoice miniVES 4001LN unit
similar to the 4001L unit with the addition of the xNET_mini 1GB/WAN/RS card with extended networking capabilities
» AutroVoice miniVES 4002 unit
to be used as a secondary unit or for smaller site applications. Equipped with four xCtrLine-2 cards and a basic xNET_mini card
» AutroVoice miniVES 4002N unit
similar to the 4002 unit, additionaly equipped with the xNET_mini 1GB/WAN/RS card with extended networking capabilities
» AutroVoice miniVES 4002L unit
primary system unit, equipped with an LCD screen and four xCtrLine-2 cards
» AutroVoice miniVES 4002LN unit
similar to the 4002L unit with the addition of the xNET_mini 1GB/WAN/RS card with extended networking capabilities
» DFMS Box unit
unit containing the DFMS reman’s microphone as a standalone solution
