COMPACT VOICE ALARM SYSTEM

SERVICE MANUAL

10. Operation instructions

10.1 Control Unit

It is possible to navigate in AutroVoice miniVES series L and LN devices menu via a touch-screen LCD display and nearby control

buttons. Thedisplay shows a current VASCU system status. The menu allows the following:

» monitor VASCU system status,

» trigger loudspeaker line impedance measurement,

» check network settings,

» check software and rmware versions.

In case of damage in at least one of the system modules, the LCD display will show information about the fault.

The paragraph below describes operation instructions with an example of microphone panel conguration. The microphones are

congured on a case-by-case basis for a specic purpose. During the rst training, the person responsible for starting the system

provides the microphone operation manual.

10.2 Fireman microphone

Actions described below can executed by authorize personnel only.

Sending verbal messages to given re zones (reman microphone)

Open red “Evacuation” button ap and press it. At this moment VASCU will switch into alarm mode. However AutroVoice

miniVES system is not equipped with the red button protected by the ap. That means that pressing once the red button

on the front panel of AutroVoice miniVES activates the 5 seconds procedure (Evacuation button starts blinking RED) during

which the system waits for second press of the button. Finishing this two steps procedure activates Alarm Mode.

Press a button applying to a desired zone. You can choose more than one zone. Green LEDs will light up next to selected zones.

» Press “Push to Talk” button, hold the button and speak to the microphone. To nish transmitting, release the button.

» Once the verbal message transmission has nished, the microphone status LED will go out.

» To return to normal mode, press “cancel alarm” button.

Sending verbal messages to all zones

» Open red “Evacuation” button ap and press it. VASCU will switch into alarm mode.

» Press “all zones” button. All of the green LEDs next to buttons corresponding with zones will light up.

» Press “Push to Talk” button. While holding the button, speak to the microphone. To nish transmitting, release the button.

» Once the verbal message transmission is nished, the microphone status LED will go out.

» To return to normal mode, press “cancel alarm” button.
