Smart Tachograph EFAS-4.10/4.11
Symbol Meaning
II
Fortnight’s driving time
20.11 Printouts
Table 33 — Symbols for printouts
Symbol Meaning
24h
Daily driver activity printout from the smart-card
24h
Daily driver activity printout from the internal memory
!
Printout of events and malfunctions from the smart-card
!
Printout of events and malfunctions from the internal memory

Printout of technical data

Printout of the card history
>>
Speed infringement printout
km/h
Vehicle speed prole (v-prole)
RPM
Logging engine speed (n-prole)
D1/D2
Logging status inputs D1 and D2

Driving time summary
SrvID
Printout of Service IDs
20.12 Event messages
Table 34 — Symbols for event messages
Symbol Events
!

Invalid smart-card inserted
!

Smart-card conict
!

Time overlap
!

Driving without suitable smart-card
!

Card inserted during driving
!

Last use of smart-card not nished correctly
>> Speed infringement
!

Interruption of power supply
!

Sensor data errors
!

Security breach
!

Time set by workshop
>

Speed infringement control
! 
Manufacturer-specic event
! 
No position information from GNSS receiver
! 
DSRC communication error
