Workshop Manual
Smart Tachograph EFAS-4.10/4.11
12.3 DTC overview table
The following table lists an overview of the DTCs (type 2 codes) dened for the tachograph system in accordance with ISO 16844-7.
Standard diagnostic tools, such as, for example, hand-held calibration instruments / tachograph tester, often display only the
ISO code of a DTC without any associated explanation of the meaning. Please refer to the following table for the meaning. The
EFAS Service Tool provides the same information when querying the fault memory.
Table 18 — DTCs supported and corresponding Service IDs
No. DTC
(hexadecimal)
Meaning Service ID
1 80 00 002007 The supply voltage of the motion sensor is above the
maximum permissible value
S1
2 80 00 002003 The supply voltage of the motion sensor is below the
minimum permissible value
S2
3 80 00 002004 Interruption of the supply voltage to the motion sensor S3
4 80 00 000007 The supply voltage of the recording equipment is above
the maximum permissible value
S4
5 80 00 000003 The supply voltage of the recording equipment is below
the minimum permissible value
S5
6 80 00 000004 Interruption of the supply voltage to the recording
equipment
S6
7 40 00 000200 Card error in slot # 1 S7, S9, S11, S13, S15, S19, S39, S90, S117,
S140, S142, S144
8 40 00 000300 Card error in slot # 2 S8, S10, S12, S14, S16, S20, S40, S91, S118,
S141, S143, S145
9 80 00 000660 No printer paper is available S21
10 80 00 002180 No real-time signal from the motion sensor (B3
interrupted)
S22
11 80 00 002280 Real-time signal from the motion sensor faulty (B3 faulty)
or invalid data signal or IMS error
S23, S83, S101
12 80 00 002380 Data signal from the motion sensor is interrupted or faulty
(B4 interrupted or faulty)
S24, S25
13 80 00 002452 Integrity error of the distance sensor S26, S27, S28, S29, S75, S76, S77, S84, S85
14 80 00 000800 Error in Date/Time S30, S93
15 40 00 000900 Motion sensor pulses with the ignition turned o S31
16 40 00 000A70 MAIN CAN bus connector faulty S32
17 40 00 000B78 MAIN CAN bus connector in “Bus O” status S33
18 40 00 000C31 Internal memory malfunction S35
19 80 00 000D33 Calibration memory, read/write error S36
20 80 00 000D40 Calibration data incorrect or incomplete S37
21 40 00 000700 Printer malfunction S38
22 40 00 000400 Malfunction of the card reader (slot # 1) S17, S41
23 40 00 000500 Malfunction of the card reader (slot # 2) S18, S42
24 40 00 000F00 Malfunction of the keyboard S43
25 80 00 002508 Malfunction of the motion sensor S45
26 40 00 003100 Malfunction in the recording equipment, pin B5
27
S46
27 40 00 003200 Malfunction in the recording equipment, pin B6
27
S47
28 40 00 003000 Malfunction in the recording equipment, pin B7 (Output
signal). The standardized output speed pulses are faulty
S48
29 40 00 003300 Malfunction in the recording equipment, pin B8
27
S49
30 40 00 004000 Malfunction in the recording equipment, pin C1
27
S50
31 40 00 004100 Malfunction in the recording equipment, pin C2
27
S51
32 40 00 004200 Malfunction in the recording equipment, pin C3
27
S52
33 40 00 004300 Malfunction in the recording equipment, pin C4
27
S53
34 40 00 004400 Malfunction in the recording equipment, pin C5
27
S54
35 40 00 004500 Malfunction in the recording equipment, pin C6
27
S55
36 40 00 004600 Malfunction in the recording equipment, pin C7
27
S56
27 This code is reserved in the standard ISO 16844-7, but recording is not necessary at present. EFAS does not support this error code.
